Starter-Generator Electronic 500 W

Starter-Generators Electronic 500 W is our electronic box for starter-generator systems with up to 500 watts of nominal output power. The basis of our starter-generator systems is usually a motor from our NOVA series, which is combined with the starter-generator electronic box to form a system solution.

All our electronic boxes are designed to be highly robust and feature a very favorable power-to-weight ratio. We develop and manufacture our electronic boxes at our HQ in Germany according to highest quality standards.

As for all our solutions, we can tailor the starter-generator system to your specific application. Our engineering team will help you in designing the right solution and support you in system integration.

You want more information or discuss how we can design a tailored solution for your application?
  • Super robust design for use in harsh environments
  • Standard protection class IP 54 (incl. sealed connectors)
  • Fully customizable to the requirements of your use case
  • Significant weight saving, as separate starter can be mitigated
  • Very high system efficiency
  • Market leading power-to-weight ratio
Product Type

Starter-generator electronic box

Dimensions (LxWxH)

134x82x56 mm (incl. fins)

Weight

710 g

Cooling

Air

Protection class

IP 54 (incl. sealed connectors)

Nominal voltage range of the battery (starter)

12 – 24 V

Starting voltage input DC (starter)

10 – 30 V

Nominal voltage range input (generator)

30 – 50 V

Max. current output (generator)

24 A

Max. continuous output power (generator)

500 W

Voltage output

28 V
